Mercury: 808.119UK, RG6 Coaxial Cable, 75 Ohms, Aluminium Braid, 100m

Product Overview & Key Benefits

TheEconomy RG6 75 Ohms Air Spaced Coaxial Cablewith Aluminium Braid represents a cost-effective yet high-quality solution for digital, satellite, and cable television signal transmission. With its robust construction and advanced design features, this cable is perfect for both DIY enthusiasts and professional installers looking for reliability and performance. The cable's air-spaced polyethylene dielectric and high-quality aluminium screening significantly reduce noise interference, ensuring superior signal integrity. This product is ideal for homeowners, commercial buildings, and hospitality settings where high-quality transmission is essential.

Technical Specifications & Product Details

• Length:100 metres
• Impedance:75 Ohms
• Dielectric:4.6mm diameter air spaced polyethylene
• Conductor:Solid copper clad steel (CCS), diameter 1mm
• Braid Material:Aluminium, featuring 48 x 0.12mm strands
• Screen:Aluminium/PET foil
• Overall Cable Diameter:6.6mm
• Weight:4.1kg
• Capacitance:54 pF/m
• Velocity Factor:83%
• Attenuation:@ 5MHz: 2.9 dB max./100m@ 50MHz: 5.2 dB max./100m@ 100MHz: 6.9 dB max./100m@ 200MHz: 10.2 dB max./100m@ 400MHz: 14.9 dB max./100m@ 860MHz: 20.3 dB max./100m@ 1000MHz: 22.5 dB max./100m@ 1750MHz: 29.8 dB max./100m@ 2150MHz: 33.6 dB max./100m
• Return Loss:5-400MHz: 24 dB min./100m450-1000MHz: 20 dB min./100m1000-2150MHz: 16 dB min./100m

Ideal Uses & Applications

The Economy RG6 coaxial cable is perfectly suited for a variety of applications including:

• Domestic DIY Projects:Ideal for home entertainment systems needing reliable signal transmission for TV and satellite services.
• Commercial Installations:Suitable for retail and office environments that require robust signal connectivity.
• Hospitality Settings:Perfect for hotels and accommodations offering high-quality cable services to guests.
• Broadcast and Production:A reliable choice for professionals needing dependable signal delivery in broadcast setups.
• DIY Community:This cable is an excellent option for hobbyists and tinkerers looking to create custom AV setups.

Energy Efficiency & Cost Savings

This coaxial cable is designed to deliver high transmission quality with reduced signal loss, which can lead to lower energy consumption and efficiency. By providing clearer signals, users can enjoy enhanced performance from their digital devices while potentially lowering their electricity bills. As an investment in quality equipment, choosing the Economy RG6 coaxial cable can result in significant long-term savings and minimise operational disruptions.
