Adastra: 953.204UK, RS Series 100V Line Slave Amplifier, 480W, Rack-Mountable, Class-D, 19"

Product Overview & Key Benefits

The RS Series 100V Line Slave Amplifiers represent a pinnacle of audio amplification technology, designed to deliver high power and efficiency for your sound system needs. Perfect for medium to large installations, these amplifiers excel in a myriad of environments, including commercial spaces, hospitality settings, and even larger domestic setups. The class-D design ensures reliable performance while providing significant weight savings, making them ideal for rack-mounted configurations.

Technical Specifications & Product Details

• Model:RS Series 100V Line Slave Amplifiers
• Supplier SKU:953.204UK
• Variant:480W 2U
• Weight:10.4 kg
• Dimensions:433 mm (W) x 355 mm (D) x 89 mm (H)
• Output Power:480W RMS
• Frequency Response:90Hz-20kHz (100V), 17Hz-90kHz (2Ω)
• THD:<1.0%
• Input Signal:Slave line in (RCA/screw terminal), 100V in (screw terminal)
• Outputs:100V or low impedance (2 Ohms min., switchable on RS121 and RS241)
• Power Supply:175-264Vac 50Hz (IEC)
• Fuse Rating:T6.3A
• Mute Function:24V alarm contacts (screw terminal)
• Controls:Master volume
• Input/Output Connections:RCA sockets or hard-wired via removable screw terminals

Ideal Uses & Applications

The versatility of the RS Series 100V Line Slave Amplifiers makes them suitable for a broad range of applications. They are particularly effective in:

• Commercial Buildings:Providing reliable sound amplification for announcements or background music in retail stores or office buildings.
• Hospitality Settings:Enhancing the audio experience in restaurants, hotels, and event venues, where high-quality sound is critical.
• Educational Institutions:Amplifying audio in classrooms, lecture halls, and auditoriums for clear sound delivery.
• Domestic Use:Ideal for home theatre systems, where users can take advantage of the impressive audio capabilities in a domestic setting.

Energy Efficiency & Cost Savings

One of the standout features of the RS Series Amplifiers is their class-D technology, which not only provides high power output but also enhances energy efficiency. These amplifiers are designed to operate more efficiently than traditional amplifiers, translating to lower electricity consumption over time. Users can expect significant cost savings on energy bills, with many installations noting reductions of up to 50 percent compared to less efficient amplifier units.

Additionally, by allowing users to extend existing 100V installations without needing extensive rewiring, these amplifiers reduce both the material costs and labour associated with installation. In an era where energy efficiency is paramount, investing in the RS Series 100V Line Slave Amplifiers represents a sound financial decision for both immediate and long-term operational costs.
