Citronic: 178.706UK, CUBA Active Full-Range PA Cabinets, 100W, DSP, Bluetooth, 6.5" Driver
About this product
CUBA Active Full-Range PA Cabinets with DSP + Bluetooth®
Premium full-range active speaker cabinets with minimalist texture coated MDF enclosure and powder-coated steel grille. Integral high-efficiency class-D amplifier sections are controlled by a 5-preset DSP which controls high detail and can extend the response down to sub-frequencies for an uncompromising full-range output. A switchable Mic/line input and a line input have XLR or jack input and the line input also has RCA option and a Bluetooth receiver for wireless playback from a smart phone. Each cabinet has 2 side handles and a 35mm pole-mount socket for stand mounting. The rear of the cabinet has 2 different bevels for angled placement at ground level or for suspended arraying, multiple M8 flying points are inset on each cabinet. Designed to provide clean, high-energy output across the full audio spectrum for all sound reinforcement applications.
- Efficient and lightweight class-D bi-amplifier
- High power full-range output
- 5 profile DSP section
- Bluetooth receiver
-
Download
Specifications
Specifications
| Inputs | Mic/line (XLR/jack), Line (RCA/XLR/jack), Bluetooth |
|---|---|
| Weight | 6.1 kg |
| Max. SPL | 115.0 dB |
| HF Driver | 25 mm (1") silk dome tweeter |
| Voice Coil | 25 mm Ø (1") |
| Line Output | XLR |
| Main Driver | 165 mm Ø (6.5") |
| Sensitivity | 92 dB |
| Construction | Polyurea coated MDF + powder-coated steel grille |
| DSP Settings | Normal, DJ, Voice, Live, Flat |
| Power Supply | 230 Vac, 50 Hz (IEC) |
| HF Dispersion | 100° x 100° |
| Frequency Response | 80 Hz - 18.5 kHz |
| Output Power (RMS) | 100 W |
| Output Power (Max.) | 200 W |
